Lighting for Vision System LVS E-mail >> lvs@lvs.co.kr 30 Internet Web Service >> www.lvs.co.kr 31 DRT / DRF

DIRECT RING LIGHTING SERIES DIRECT RING LIGHTING SERIES
LV-DRT Series LV-DRF Series
DLA2 / DL

LV-DRT-99C LV-DRT-118C LV-DRF-42R LV-DRF-54R

Color Option ● SW ● RD ● GR ● BL Color Option ● SW ● RD ● GR ● BL Color Option ● SW ● RD ● GR ● BL Color Option ● SW ● RD ● GR ● BL DB / DB2
Power Consumption(W) 7.2 4.4 7.2 7.2 Power Consumption(W) 12.6 7.6 12.6 12.6 Power Consumption(W) 1.8 1.1 1.8 1.8 Power Consumption(W) 3.6 2.2 3.6 3.6
Voltage 12V / 24V Voltage 12V / 24V Voltage 12V / 24V Voltage 12V / 24V
Number of LEDs 120EA Number of LEDs 210EA Number of LEDs 30EA Number of LEDs 60EA
IFRK

ILA-R/ILA-S

IDM

IFS

LV-DRT-146C LV-DRT-172C LV-DRF-68R LV-DRF-82R
Color Option ● SW ● RD ● GR ● BL Color Option ● SW ● RD ● GR ● BL Color Option ● SW ● RD ● GR ● BL Color Option ● SW ● RD ● GR ● BL
Power Consumption(W) 16.2 9.8 16.2 16.2 Power Consumption(W) 25.2 15.2 25.2 25.2 Power Consumption(W) 5.4 3.3 5.4 5.4 Power Consumption(W) 7.2 4.4 7.2 7.2 DDM
Voltage 12V / 24V Voltage 12V / 24V Voltage 12V / 24V Voltage 12V / 24V
Number of LEDs 270EA Number of LEDs 420EA Number of LEDs 90EA Number of LEDs 120EA
ICFV / ICFV2

IFD

SHL / SVL

UV / IR

LV-DRF-96R LV-DRF-117R
Color Option ● SW ● RD ● GR ● BL Color Option ● SW ● RD ● GR ● BL
Power Consumption(W) 10.8 6.5 10.8 10.8 Power Consumption(W) 14.4 8.7 14.4 14.4 HLS
Voltage 12V / 24V Voltage 12V / 24V
Number of LEDs 180EA Number of LEDs 240EA
EN / ES / ET

DN / DS

HPLS

UVH
