LVS-ES-SERIES PARTS DESCRIPTION
● Strobe light on-time controller in 1μs interval on-time control, up to 999μs DDM
Product Feature ● Up to 8-Channels for illumination
● Led intensity control via external communication and front panel manual control.
192.5 192.5
(Fine control up to 999 steps) ICFV / ICFV2
● External Communication Device Support Coarse Ethernet
Switch 294 294 Volume RS232C
- Ethernet (TCP/IP & UDP, 10/100 base-T Support), RS232C (Baud-rate : 19,200) 32 32 230 230 2X2-M3 TAP Switch
THRU 2X2-M3 TAP External
THRU
● Display device support for System Status and Control ERROR SEL ES-0824 ES-0824 Mode Trigger Port IFD
Switch VOLUME Switch
COARSE LOCK ERROR GRN : ACT YLW : LINK GRN : ACT LIGHT OUTPUT LIGHT OUTPUT
x10 YLW : LINK
LOCK
COARSE
x10 Pulse Width ( )
VOLUME
Pulse Width ( ) PUSH TO LOCK EXT PUSH TO LOCK ETHERNET RS-232C ETHERNET RS-232C EXPANSION PORT EXPANSION PORT
(Lock LED, Channel LED, 7-Segment LED) SEL ALL 1 5 SEL 2 6 CHANNEL 1 5 3 7 2 6 4 8 MODE 3 7 4 8 INT MODE EXT 141 70 141 70 Light
INT
ALL
TRIG FALLING TRIG TRIG EDGE ALL CHANNEL ON ON Output
RISING FALLING RISING TRIG EDGE POWER OFF OFF 35 100 ~ 240VAC 50 / 60Hz 100 ~ 240VAC 50 / 60HzPower
● External Trigger Input Port LED Illuminator Strobe Controller POWER 35 8A / 100VAC 8A / 100VAC Switch AC Input
Switch
LED Illuminator Strobe Controller
● Lock / Unlock and Auto-Save features Display 7 7 280 280 Trigger Edge SHL / SVL
Select Switch
SPECIFICATION
│ ES-04 Series FRONT PANEL │ │ ES-04 Series REAR PANEL │
Model Name ES-02xx ES-/04xx ES-08xx UV / IR
Intensity Method Strobe
On-Time 0~999 μs
Number of Channels 2 4 8 HLS
Output Voltage DC 24 V / DC 48 V
Connector SMP-02V (24Vdc) / SMP-03V (48Vdc)
Power 150W 300W 600W EN / ES / ET
Maximum Current(Single Channel) 24V : 6A, 48V : 3.125A 6A
Maximum Current(All-Channel Used) 24V : 3.125A, 48V : 1.56A
Maximum Power(Single Channel) 24V : 144W, 48V : 150W 24V : 144W, 48V : 288W
Maximum Power(All-Channel Used) 75W DN / DS
Communication(PC Interface) External [RS-232C(19,200), Ethernet(10/100base-T)]
Operating Environment Temperature 0℃~30℃, Humidity 20~80% RH (with no condensation)
Storage Environment Temperature -15℃~ 60℃, Humidity 20~85% RH (with no condensation) HPLS
Input Voltage AC 100~240V, 50/60Hz
▶ Maximum Current(Single Channel) : Maximum output when using a single channel @ on-time : 1[ms] & Interval : 10[ms]
▶ All-Channel Used : Maximum output per channel when all channels are used. UVH
